Batteries – lead-acid equivalents
This is a list of commonly found lead-acid batteries with their dimensions in millimetres, open circuit voltage and their approximate mass in kilograms…
Type |
Height (mm) |
Width (mm) |
Depth (mm) |
voltage (V) |
Capacity (amp hours) |
Mass (kg) |
Max current burst (A) |
NP 1-6 |
55 |
51 |
42 |
6 |
1 |
0.25 |
45 |
NP 1.2-6 |
54 |
97 |
25 |
6 |
1.2 |
0.3 |
45 |
NP 2.8-6 |
64 |
134 |
34 |
6 |
2.8 |
0.56 |
100 |
NP4-6 |
108 |
70 |
46 |
6 |
4 |
0.85 |
120 |
NP 7-6 |
98 |
151 |
33 |
6 |
7 |
1.28 |
180 |
NP 10-6 |
98 |
151 |
50 |
6 |
10 |
2 |
300 |
NP 1.2-12 |
55 |
97 |
47 |
12 |
1.2 |
0.6 |
45 |
NP 2.1-12 |
66 |
178 |
34 |
12 |
2.1 |
0.83 |
75 |
NP 2-12 |
90 |
150 |
20 |
12 |
2 |
0.7 |
80 |
NP 2.8-12 |
64 |
134 |
68 |
12 |
2.8 |
1.1 |
100 |
NP 4-12 |
105 |
90 |
70 |
12 |
4 |
1.75 |
120 |
NP 6-12 |
98 |
151 |
65 |
12 |
6 |
2.4 |
180 |
NP 17-12 |
167 |
180 |
76 |
12 |
17 |
5.9 |
400 |
NP 24-12 |
125 |
175 |
165 |
12 |
24 |
8.65 |
500 |
NP 38-12 |
170 |
196 |
165 |
12 |
38 |
13.8 |
500 |
