TV sound frequencies, CCIR countries (mainly EU)
This is the list of television audio carrier frequencies for CCIR countries – which includes many but not all the countries in the EU. UK, Ireland France & Italy have their own systems. Obviously you need a radio receiver capable of receiving these frequencies, such as the AOR 8200 or the Icom IC-R20. Or you could just use a localised TV of course!
Anyway we created a series of these tables, based upon the data supplied with the Icom IC-R20 and from various websites. So now you can listen to the TV wherever your travels may take you!
Channel |
Frequency (MHz) |
Modulation |
|---|---|---|
1 |
46.750 |
WFM |
2 |
53.750 |
WFM |
3 |
60.750 |
WFM |
4 |
67.750 |
WFM |
5 |
180.750 |
WFM |
6 |
187.750 |
WFM |
7 |
194.750 |
WFM |
8 |
201.750 |
WFM |
9 |
208.750 |
WFM |
10 |
215.750 |
WFM |
11 |
222.750 |
WFM |
12 |
229.750 |
WFM |
21 |
476.750 |
WFM |
22 |
484.750 |
WFM |
23 |
492.750 |
WFM |
24 |
500.750 |
WFM |
25 |
508.750 |
WFM |
26 |
516.750 |
WFM |
27 |
524.750 |
WFM |
28 |
532.750 |
WFM |
29 |
540.750 |
WFM |
30 |
548.750 |
WFM |
31 |
556.750 |
WFM |
32 |
564.750 |
WFM |
33 |
572.750 |
WFM |
34 |
580.750 |
WFM |
35 |
588.750 |
WFM |
36 |
596.750 |
WFM |
37 |
604.750 |
WFM |
38 |
612.750 |
WFM |
39 |
620.750 |
WFM |
40 |
628.750 |
WFM |
41 |
636.750 |
WFM |
42 |
644.750 |
WFM |
43 |
652.750 |
WFM |
44 |
660.750 |
WFM |
45 |
668.750 |
WFM |
46 |
676.750 |
WFM |
47 |
684.750 |
WFM |
48 |
692.750 |
WFM |
49 |
700.750 |
WFM |
50 |
708.750 |
WFM |
51 |
716.750 |
WFM |
52 |
724.750 |
WFM |
53 |
732.750 |
WFM |
54 |
740.750 |
WFM |
55 |
748.750 |
WFM |
56 |
756.750 |
WFM |
57 |
764.750 |
WFM |
58 |
772.750 |
WFM |
59 |
780.750 |
WFM |
60 |
788.750 |
WFM |
61 |
796.750 |
WFM |
62 |
804.750 |
WFM |
63 |
812.750 |
WFM |
64 |
820.750 |
WFM |
65 |
828.750 |
WFM |
66 |
836.750 |
WFM |
67 |
844.750 |
WFM |
68 |
852.750 |
WFM |
69 |
860.750 |
WFM |
