TV sound frequencies, USA

ByGarf created updated

This is the list of television audio carrier frequencies for the United States. Obviously you need a radio receiver capable of receiving these frequencies, such as the AOR 8200 or the Icom IC-R20. Or you could just use a localised TV of course!

Editor’s note: Most countries have now ceased transmitting analogue television. This table of TV sound frequencies is retained primarily for historical and reference purposes.

Anyway we created a series of these tables, based upon the data supplied with the Icom IC-R20 and from various websites. So now you can listen to the TV wherever your travels may take you!

Channel Nr.
Frequency (MHz)
Modulation Type
TV Standard
2
59.75
WFM
M
3
65.75
WFM
M
4
71.75
WFM
M
5
81.75
WFM
M
6
87.75
WFM
M
7
179.75
WFM
M
8
185.75
WFM
M
9
191.75
WFM
M
10
197.75
WFM
M
11
203.75
WFM
M
12
209.75
WFM
M
13
215.75
WFM
M
14
475.75
WFM
M
15
481.75
WFM
M
16
487.75
WFM
M
17
493.75
WFM
M
18
499.75
WFM
M
19
505.75
WFM
M
20
511.75
WFM
M
21
517.75
WFM
M
22
523.75
WFM
M
23
529.75
WFM
M
24
535.75
WFM
M
25
541.75
WFM
M
26
547.75
WFM
M
27
553.75
WFM
M
28
559.75
WFM
M
29
565.75
WFM
M
30
571.75
WFM
M
31
577.75
WFM
M
32
583.75
WFM
M
33
589.75
WFM
M
34
595.75
WFM
M
35
601.75
WFM
M
36
607.75
WFM
M
37
613.75
WFM
M
38
619.75
WFM
M
39
625.75
WFM
M
40
631.75
WFM
M
41
637.75
WFM
M
42
643.75
WFM
M
43
649.75
WFM
M
44
655.75
WFM
M
45
661.75
WFM
M
46
667.75
WFM
M
47
673.75
WFM
M
48
679.75
WFM
M
49
685.75
WFM
M
50
691.75
WFM
M
51
697.75
WFM
M
52
703.75
WFM
M
53
709.75
WFM
M
54
715.75
WFM
M
55
721.75
WFM
M
56
727.75
WFM
M
57
733.75
WFM
M
58
739.75
WFM
M
59
745.75
WFM
M
60
751.75
WFM
M
61
757.75
WFM
M
62
763.75
WFM
M
63
769.75
WFM
M
64
775.75
WFM
M
65
781.75
WFM
M
66
787.75
WFM
M
67
793.75
WFM
M
68
799.75
WFM
M
69
805.75
WFM
M
